Thermal transfer ribbon

Thermal transfer ribbon Applications/Product overview

Article control, tag, ticket

Article control

  • Transportation control
  • Inventory control
  • POS
  • Physiological fluid control

Tag

  • Price tag
  • Brand tag

Ticket

  • Entrance ticket
  • Railroad ticket
  • ATB
  • Betting slip

B110A

Product B110A
Color Black
TTR grade Wax-Resin
Resistance to smear and heat 50°c(122 F)
Features
  • High resolution
  • 50°c corrugated cardboard scrape resistance
Applications
  • General use when barcode readability is specifically required.
  • Strong against high temperature and vibration during transportation and suitable for delivery and distribution control.

B120E

Product B120E
Color Black
TTR grade Wax-Resin
Resistance to smear and heat 30°c(86 F)
Features
  • High resolution
  • For low-smoothness paper
Applications
  • General use when barcode readability is specifically required.
  • For low-smoothness paper like tickets.

Product overview

Most suitable:Most suitable / Suitable:Suitable / Not suitable:Not suitable

B110A
Smearless		 B120E
for edge head
Smearless
TTR grade Wax-Resin Wax-Resin
Receiver Matching Quality Paper base Lightweight coated paper Most suitable Most suitable
Coated paper Most suitable Most suitable
Gloss paper Most suitable Most suitable
Film base PE(polyethylene) Most suitable Most suitable
PP(polypropylene) Most suitable Most suitable
PVC(polyvinylchloride) Most suitable Most suitable
PET(polyester) Most suitable Most suitable
PI(polyimide) Most suitable Most suitable
Cloth base Nylon Most suitable Most suitable
Polyester Most suitable Most suitable
Acetate Most suitable Most suitable

Date coding

Date coding

  • Expiration date of foodstuffs
  • Direct printing on package(e.g. medicine, auto parts)
Product B120HS
Color Black
TTR grade Resin
Features
  • For PE,PP
  • High image density
  • Scratch resistance
Applications
  • Suitable for PE, PP which are main packaging materials for food.
  • Clear image is possible even on transparent package because printed image blocks light.
  • No spoiling of image during transportation and handling of food.
Product D110A
Color Black
TTR grade Resin
Features
  • For nylon
  • High heat resistance
Applications
  • Suitable for heat-resistant nylon packages which are often boiled.

Product overview

Most suitable:Most suitable / Suitable:Suitable / Not suitable:Not suitable

B110A
Smearless		 B120HS
Scratch resistance		 D110A
Heat resistance
Wash resistance
TTR grade Wax-Resin Resin Resin
Receiver Matching Quality Paper base Lightweight coated paper Most suitable Not suitable Not suitable
Coated paper Most suitable Not suitable Not suitable
Gloss paper Most suitable Not suitable Not suitable
Film base PE(polyethylene) Most suitable Most suitable Not suitable
PP(polypropylene) Most suitable Most suitable Not suitable
PVC(polyvinylchloride) Most suitable Not suitable Not suitable
PET(polyester) Most suitable Not suitable Most suitable
PI(polyimide) Most suitable Not suitable Most suitable
Cloth base Nylon Most suitable Not suitable Most suitable
Polyester Most suitable Not suitable Most suitable
Acetate Most suitable Not suitable Most suitable

Indication, manufacturing process control

Indication

  • Nameplate
  • Rating plate
  • Drum label, pail label
  • Plastic card
  • Signboard

Manufacturing process control

  • Assembly (electric appliance, etc.)
  • Blood bag
Product B110C B110CR
Color Black Black
TTR grade Resin Resin
Resistance to smear and heat 100°c(212 F) 100°c(212 F)
Features
  • 100°c corrugated cardboard scrape resistance
  • Solvent resistance (ethanol, kerosene, engine oil)
  • Ultra solvent resistance (for application requires more higher solvent resistance than B110C)
  • 600DPI resolution
Applications
  • For nameplate which is cleaned with alcohol when being finished.
  • For automobile manufacturing process control
  • For small characters & barcodes in name plate.
  • For super duty use

Ultra chemical resistance printing media

Product B110CU RFR
Classification TTR Specified receiving material
Color Black White/Silver
TTR grade Resin Designed for B110CU
Base material:PP base
Features
  • Ultra chemical resistance (ethanol, IPA, acetone, MEX, thinner, xylene, brake-fluid, water)
  • 100°c corrugated cardboard scrape resistance
  • Scratch resistance
  • UL approval
  • Thermal printing becomes possible even in processes where many solvents are used.
Applications
  • For transportation equipment, parts nameplate, process control where heavy solvent is used for finish cleaning.
  • For chemical label on drum or container which is exposed to heavy solvents.
  • For medical applications (e.g. control diagnostic of pathologic histology)

TTR + Over-Laminatinn

  • Have to prepare 2 supplies (TTR+lamination)
  • High cost of lamination

Metal Tag

  • Long lead time to prepar
  • High cost

Hand-Writing

  • Hand operation is awkward
  • Potential for errors

High solvent resistance recording media increases opportunities to adopt barcode solutions!

High solvent resistance recording media stands for high reliability thermal transfer ink and exclusive receiving film. This can endure toluene, thinner, MEK, acetone, etc which conventional resin ink can't be applied. In addition damages of printing image by scratch can be prevented.
This new feature enables users to switch from other printing methods to barcode solutions. Consequently, barcode printing's benefits (on-demand printing, auto-recognition control, and low cost) can be created in new fields where strong solvents exist.

New barcode solution opportunities

  • Transportation equipment (Rating Plate, Process Control)
  • Electronic Product(Rating Plate, Process Control)
  • Ultrasonic Cleaning(Rating Plate, Lot Nr indication)
  • Chemical (Indication Label)
  • Medical (Pathology Specimens)

B120EC line (for edge head, resistance to smear and heat, solvent resistance)

Product B120EC
Color Black
TTR grade Resin
Resistance to smear and heat 100°c(212 F)
Features
  • 100°c corrugated cardboard scrape resistance
  • Solvent resistance (ethanol, kerosene, engine oil)
  • Scratch resistance
Applications
  • For nameplate which is cleaned with alcohol when being finished.
  • For automobile manufacturing process control
  • For contacting hard items like cards and rental videocassettes.

Product overview

Most suitable:Most suitable / Suitable:Suitable / Not suitable:Not suitable

B120HS
Scratch resistance		 B110C
Resistance to smear and heat
Solvent resistance		 B120EC
for edge head Resistance to smear
and heat Solvent resistance		 D110A
Heat resistance
Wash resistance
TTR grade Resin Resin Resin Resin
Receiver Matching Quality Paper base Lightweight coated paper Not suitable Not suitable Not suitable Not suitable
Coated paper Not suitable Not suitable Not suitable Not suitable
Gloss paper Not suitable Not suitable Not suitable Not suitable
Film base PE(polyethylene) Most suitable Suitable Suitable Not suitable
PP(polypropylene) Most suitable Suitable Suitable Not suitable
PVC(polyvinylchloride) Not suitable Most suitable Most suitable Not suitable
PET(polyester) Not suitable Most suitable Most suitable Most suitable
PI(polyimide) Not suitable Most suitable Most suitable Most suitable
Cloth base Nylon Not suitable Not suitable Not suitable Most suitable
Polyester Not suitable Not suitable Not suitable Most suitable
Acetate Not suitable Not suitable Not suitable Most suitable

Cleaning

Cleaning

  • Care label
  • Linen supply control
  • Laundry identification
  • Cloth label (e.g. seatbelt, mop, mat)

D110A

Product D110A D210A D310A
Color Black Navy Red
TTR grade Resin Resin Resin
Features
  • Printing on cloth (nylon, polyester, acetate)
  • Wash resistance
  • Water: 80°c, 20 minutes
  • Dry cleaning: Perchloroethylene 40°c, 30 minutes
  • Ironing resistance (150°c)
  • Printing on cloth (nylon, polyester, acetate)
  • Wash resistance
  • Water: 80°c, 20 minutes
  • Dry cleaning: Perchloroethylene 40°c, 30 minutes
  • Ironing resistance (150°c)
  • Printing on cloth (nylon, polyester, acetate)
  • Wash resistance
  • Water: 80°c, 20 minutes
  • Dry cleaning: Perchloroethylene 40°c, 30 minutes
  • Ironing resistance (150°c)
Applications
  • Care label, linen and cloth products (e.g. seatbelt, mop, mat) indication label.
  • Navy color printing on care label for underwear.
  • Corporate logo printing on care label.
  • Identification for washing and distribution.
  • Care label prohibition X mark
  • Corporate logo printing on care label.
  • Identification for washing and distribution.

Appropriation of other product lines

Product B120HS D110A
D210A
D310A
Color Black Black/Navy/Red
TTR grade Resin Resin
Features
  • For polyolefine film like PP, PE
  • For film like PI (polyimide), PET
  • High heat resistance
  • Solvent resistance (gasoline, kerosene, engine oil)
Applications
  • Suitable for usage of PP, PE for process control label, the surface of which is not treated for purposes of cost reduction.
  • Heat-resistant application such as 200°c steaming process for blood formulation agent.
  • Color coding identification for process control.

Product overview

Most suitable:Most suitable / Suitable:Suitable / Not suitable:Not suitable

D110A line
Heat resistance
Wash resistance
TTR grade Resin
Receiver Matching Quality Paper base Lightweight coated paper Not suitable
Coated paper Not suitable
Gloss paper Not suitable
Film base PE(polyethylene) Not suitable
PP(polypropylene) Not suitable
PVC(polyvinylchloride) Not suitable
PET(polyester) Most suitable
PI(polyimide) Most suitable
Cloth base Nylon Most suitable
Polyester Most suitable
Acetate Most suitable
